0-3" BP-51 Lift Kit with Upper Control Arms Tacoma (2016-2023)

Old Man Emu

0-3" BP-51 Lift Kit with Upper Control Arms Tacoma (2016-2023)

Sale price$4,422.00 USD
SKU: ARBTACBP51P
Load:

Load

In Stock - 13 available In Stock - 13 available

Product Description

Old Man Emu brings racing technology to every day adventures: BP-51 (Bypass 51mm diameter bore) shock absorbers feature revolutionary, patent pending technology developed to deliver unparalleled on and off road performance. Developed and extensively tested under the harshest conditions in Australia, these big bore, position sensitive bypass shock absorbers with remote reservoir are designed to bolt onto your vehicle without any vehicle modifications and combine considerable ride comfort around town with significant amounts of end-zone damping for exceptional chassis control and handling off road. The damping performance is easily adjustable across a wide range of rebound and compression, resulting in significant changes to the ride performance of your vehicle, enabling a custom tune to suit the conditions and vehicle set up. The body, reservoir and components are all made from 6061 T6 aluminum, Type 3 40 micron hard anodized ensuring exceptional heat dissipation, corrosion resistance and resistance to stone damage. Not only designed, developed and tested entirely by ARB's team of Old Man Emu ride engineers, all BP-51 shock absorbers are manufactured in-house by ARB. In order to achieve this, significant investment has been made in state of the art machinery providing ARB total control of the manufacturing process to ensure the highest possible quality.

Product Features

  • Independent adjustability of both rebound and compression
  • A 6061 grade aluminum top hat
  • A 6061 grade aluminum top hat
  • Durable Dash 6 high-temperature Teflon hose optimum oil flow
  • Large, Teflon-lined spherical bearings
  • Quality oversized rubber bushings result in excellent longevity
  • Impact-resistant polyethylene guard prevents damage to shaft
  • Hard chromed, ground piston shaft for strength and durability
  • Heavy-load capacity for aftermarket bumper, winch and cargo
  • A 6061 grade aluminum top hat
  • High-quality X5K grade steel coil, for use on coil over models
  • A 6061 grade aluminum top hat

Included

Light Load

  • BP5190006R Front BP-51 Coilover for Right Side, 1
  • FK29 Rear Driveshaft Spacer, 1
  • BP5160011R Rear BP-51 Bypass Shock Absorber for Right Side, 1
  • OMESB108 Leaf Spring Bushing Kit, 2
  • VM80010017 Rear BP-51 Shock Fitting Kit, 1
  • VM80010016 Front BP-51 Shock Fitting Kit, 1
  • EL111R Rear Leaf Spring, 2
  • BP5160011L Rear BP-51 Bypass Shock Absorber for Left Side, 1
  • BP5190006L Front BP-51 Coilover for Left Side, 1
  • UCA0005 Upper Control Arms, 1
  • OMEU53B Leaf Spring U-Bolt, 4

Heavy Load

  • FK29 Rear Driveshaft Spacer, 1
  • VM80010017 Rear BP-51 Shock Fitting Kit, 1
  • BP5190006R Front BP-51 Coilover for Right Side, 1
  • UCA0005 Upper Control Arms, 1
  • BP5160011L Rear BP-51 Bypass Shock Absorber for Left Side, 1
  • BP5190006L Front BP-51 Coilover for Left Side, 1
  • EL112R Rear Leaf Spring, 2
  • OMESB108 Leaf Spring Bushing Kit, 2
  • VM80010016 Front BP-51 Shock Fitting Kit, 1
  • BP5160011R Rear BP-51 Bypass Shock Absorber for Right Side, 1
  • OMEU53B Leaf Spring U-Bolt, 4
