Front Billet Upper Control Arm Kit w/Delta Joint Pro Tundra (2022+) / Sequoia (2023+)

Product Description

The ICON billet aluminum upper control arm (UCA) kit enhances the 2022-2024 Toyota Tundra's performance by improving front-end geometry, increasing camber and caster adjustment, and providing better suspension clearance.

Made from CNC machined 6061 billet aluminum, these UCAs are lightweight and strong, featuring a hybrid H-beam cross-section. The kit replaces the original ball joint with the serviceable and rebuildable ICON Delta Joint PRO, allowing full suspension travel and eliminating bind. FK Rod End heim joints ensure precise function, while ICON’s double adjuster sleeve allows on-vehicle camber and caster adjustments. The kit includes all necessary components and hardware for installation.

The Delta Joint PRO, part of ICON's state-of-the-art suspension components, combines the durability of factory-style ball joints with superior performance, offering a 14% improvement in range of motion over the original Delta Joint. It features a rebuildable design, a larger ball for increased bearing surface, and enhanced lubrication sealing. Built for extreme durability, it includes a chromoly ball and shaft with hardened bearing surfaces, and graphite-impregnated sintered metal races for a precise metal-to-metal bearing interface. The redesigned lubrication system distributes grease efficiently without extending past the bearing seal.

Product Features

ICON Vehicle Dynamics warrants to the original retail purchaser who owns the vehicle on which the product was originally installed.
ICON Vehicle Dynamics does not warrant the product for finish, alterations, modifications and/or installation contrary to ICON Vehicle Dynamics instructions. ICON Vehicle Dynamics products are not designed, nor are they intended to be installed on vehicles used in race applications, for racing purposes or for similar activities. (A “race” is defined as any contest between two or more vehicles, or a contest of one or more vehicles against the clock, whether or not such contest is for a prize). This warranty does not include coverage for police or taxi vehicles, race vehicles, or vehicles used for government or commercial purposes. Also excluded from this warranty are sales outside of the United States of America and Canada.
ICON Vehicle Dynamics’ obligation under this warranty is limited to the repair or replacement, at ICON Vehicle Dynamics’ discretion, of the defective product. Any and all costs of removal, installation or re-installation, freight charges and incidental or consequential damages are expressly excluded from this warranty. Items that are subject to wear are not considered defective when worn and are
not covered.
ICON Vehicle Dynamics components must be installed as a complete kit as shown in our current application guide. Any substitutions or exemptions of required components will immediately void the warranty. Some finish damage may happen to parts during shipping
and is not covered under warranty.
This warranty is expressly in lieu of all other warranties expressed or implied. This warranty shall not apply to any product that has been improperly installed, modified or customized subject to accident, negligence, abuse or misuse.
